SuZhou Eshine Elevator Components Co., Ltd. Chapter 4 Function Introduction
YS-K01 Door Controller User Manual ―37―
4.5 Group P4 CD Curve Parameters
Refer to section 5.3.2 for the CD curve optimal.
Code Name Description Range
factory setting
P4.00 CD start distance 0
9999
0
P4.01 CD start speed 0.00
15.00 Hz
3.00Hz
When the door position pulse and the OD arrival position are in the CD start distance, the door
machine will run at the CD start speed.
P4.02 CD Acc time 0.1
99.9s
1.0s
CD Acc time is the time accelerated from zero frequency to the maximum frequency.
P4.03 CD speed 0.00
P0.07
18.00Hz
It defines the high operating speed (frequency) during CD process.
P4.04 CD Dec point position 50.0
90.0%
68.0%
When the pulse number ≥P4.04×door width, the door machine will decelerate from P4.03 (CD
speed) to P4.06 (creeping speed at CD ending).
• The bigger P4.04 is set, the shorter Dec distance is.
P4.05 CD Dec time 0.1
99.9s
1.1s
CD Dec time is the time decelerated from maximum frequency to zero frequency.
P4.06 Creeping speed at CD ending 0.00
15.00 Hz
1.50Hz
It defines the low creeping speed (frequency) of door machine during CD process.
P4.07 Door blade acting position at CD ending 1
210
160
When pulse number≤P4.07 setting number, the door machine will carry out CD ending and door
blade action.
P4.08 Door blade acting speed at CD ending 0.00
15.00 Hz
3.00Hz
Defines the run speed (frequency) of door blade action position in P4.07 range during the CD
process.
P4.09 CD limit point 10
200
200
When the door position is in the CD limit point position, the door machine will output CD arrival signal.
