Chapter 5 Controller Debugging SuZhou Eshine Elevator Components Co., Ltd.
―48― YS-K01 Door Controller User Manual
5.9 Debugging Guide
5.9.1 Debugging Notes
YS-K01 is a door controller with synchronous/asynchronous control mode, which is applied for
the KS series door machine (synchronous) and the MS series door machine (asynchronous).
For the convenience of customers to distinguish, the KS series door machine and the MS series
door machine are respectively shown as Figure 5-5 and Figure 5-6.
Figure 5-5 KS series door machine
Figure 5-6 MS series door machine
Note:
1. In the factory, the controller has been set the parameters. In generally the user should not
change the parameters! But the OD/CD curve parameters of Group P3 and Group P4 can be
changed according to the actual situation.
2. According to the motor’s model, the controller parameters can be reset by pressing one
key.
3. The follows of debugging steps can be used in such situation as: replace the YS-K01 or
the motor or the encoder of KS series door machine on the scene.
