4.10 Group P9 Diagnostics Parameters
Code Name Description Range
【
factory setting
】
P9.00
NO.3 fault type (last fault)
【
actual value
】
P9.01 NO.2 fault type
P9.02
NO.1 fault type
P9.03 DC bus voltage for last fault
P9.04
Output current for last fault
P9.05 Running frequency for last fault
P9.06
Door position for last fault
P9.07 Open-close cycle lower value
P9.08
Open-close cycle upper value
P9.09 Running hour
P9.10
Running day
P9.11 Heatsink temperature
P9.12
Controller software version
P9.13 Panel software version
0: Normal.
1: Controller overvoltage (E001).
2: Controller hardware overcurrent (E002).
3: Controller software overcurrent (E003).
4: Loss of Z phase signal of permanent magnet synchronous motor encoder (E004).
5: Machine type mismatch (E005).
6: Motor parameter auto-tuning fault (E006).
7: Controller overloaded (E007).
8: Heatsink overheated (E008).
9,10: Reserved.
11: Panel EEPROM faulty (E011).
12: Reserved.
13: Communication fault between the panel and the controller (E013).
14: Controller EEPROM faulty (E014).
15,16: Reserved.
17: Module faulty (E017).
18: Current detect faulty (E018).
19－22: Reserved.
23: Encoder error (E023).
24,25: Reserved.
26: Door width self-learning failure (E026).
-Lu-: Undervoltage.
