ETAS Technical Data
ES930.1 - User Guide 100
13.9.8 Power Stage ("PS" Connection)
13.9.8.1 Half-bridges
For the Half-bridges, the driver ICs Infineon TLE7182EM are used.
The data sheet "TLE7182EM H-Bridge and Dual Half-bridge Driver IC (Data
Sheet, Rev 1.1, Sept. 2010)" with detailed information is available on the
Infineon Internet page.
Number of channels 6 Half-bridges
Power supply of Half-bridges Separate, 7 V DC to 32 V DC
Activation of Half-bridges One digital output controls the two
switches of a Half-bridge
Switching current ±5 A rated current (max., per channel)
±7 A short-term current peaks (max.,
per channel)
20 A max. rated current at power sup-
ply plus or minus
Frequency 20 kHz (max.)
Minimum pulse width for Half-bridge
switch
2.5 s (min.)
Electrical isolation All 6 Half-bridges together as channel
group to the supply voltage of the
module and to housing
Fault protection of Half-bridges Switch-off at overtemperature, over-
current, short-circuit
Monitoring, fault protection and
switch-off always jointly for two Half-
bridges (channels 1 and 2, channels 3
and 4, channels 5 and 6)
Setting of diagnostics bit at switch-off
Maximum voltage Limitation (clamping) of the output
voltage to the external power supply
of the half-bridges
Output-to-ground of voltage supply of
the module:
60 V DC / 30 V AC
Output-to-housing:
60 V DC / 30 V AC
Assemblies Half-bridge consists of 2 push-pull
switches with current measurement
(current input), diagnostics assembly
Functions Depending on the configuration and
connection as high-side, low-side,
half-bridge switch (Full-bridge through
external connection)
