ETAS Pin Assignment and Accessories
ES930.1 - User Guide 124
14.3.2.3 CBEP415.1 Cable
Fig. 14-21 CBEP415.1 Cable
Connection of an ES4xx/ES63x/ES93x module to PC and power supply (stand-
alone operation). Supply battery at the other end (i.e. in the trunk). Robust,
waterproof and dust-proof (IP67).
14.3.2.4 CBEP4155.1 Cable
Fig. 14-22 CBEP4155.1 Cable
Connection of an ES4xx/ES63x/ES93x module to PC and power supply (stand-
alone operation). Supply battery at the other end (i.e. in the trunk). Robust,
waterproof and dust-proof (IP67).
Product Length Order number
CBEP415.1-5 5 m F 00K 105 680
Product Length Order number
CBEP4155.1-5 5 m F 00K 110 027
