ETAS Technical Data
ES930.1 - User Guide 92
13.9 Electrical Data
13.9.1 Power Supply
13.9.2 Host ("IN" Connection)
NOTE
Unless described otherwise, the electrical data of the ES930.1 were mea-
sured directly at the contacts of the module.
Operating voltage Operating voltage for the module at
"IN" connection:
7 V to 29 V DC
Separate operating voltage for the
Half-bridges at "PS" connection:
7 V to 32 V DC
Power consumption
1)
Typ. 4.5 W at 12 V
Power consumption
2)
Typ. 7.8 W at 12 V
Power consumption Max. 15 W
Overvoltage category
(AC mains supply)
II
1)
: without sensor supply
2)
: with sensor supply, 30 mA load at 15 V
Connection 100Base-T Ethernet; 100 Mbit/s,
full duplex
Protocol XCP on UDP/IP
IP address Dynamic via INCA or
ES93x
Configuration Tool
(default setting 192.168.40.44)
NOTE
For the successful initialization of the network card of your PC, observe chap-
ter 13.8.2 on page 90.
