14 Using About 175
{Device Details} - appears when the current address is patched to a RDM device. RDM devices
must be enabled through the ECU and discovered through the patch. See Enable RDM, page 236
and {Patch} Display and Settings, page 61.
{Device Details} displays the information that it receives from the device and allows some changes
to be made to:
• Device Label (displayed at the top by the address number)
• DMX Address (can be changed in this display by clicking on the property or value)
• DMX Label (same as the device label, but the label can be changed here by clicking on
the property or value)
• Type
• Manufacturer
• Device ID
•Footprint
• Version
• Lamp State
• Lamp Hours
• Head DC Voltage
• Lamp On/Off
• Gel Distance Traveled
• Gel2 Distance Traveled
•Fan RPM
• Ambient Temperature
• Gel Temperature
• Device Errors (will only display if there are current errors)
• Clear Errors
Device Errors are displayed in four different colors depending on severity. The severity of the error
is determined by the manufacturer of the device.
• Gray - Unknown or not an error
• White - Advisory
• Yellow - Warning
•Red - Error
Note:
Changes may take a few seconds to take effect. They will propagate to the RDM
device and then back to the console’s patch and about displays.
Note:
You may change the starting address on RDM devices, but the port/universe is
fixed by the device’s connection to the gateway. To change the universe., the
device must be connected to a different gateway port in the system.
Note:
Details displayed will vary based on the device.
