F Remote Control 257
Appendix F
Remote Control
Remotes Overview
Three different remotes are available for controlling Element; the phone remote, the radio focus
remote, and the iRFR/aRFR.
Phone Remote
The phone remote allows for remote control of the Element console by using a wireless phone. The
base station for the phone connects directly to the phone remote jack on the rear of your console.
See “Console Geography” on page 12.The numeric keypad of the phone is used to control
channels and levels.
Phone Remote Functions
The numeric keypad of the phone is mapped as following:
To use the commands in gray, first hit the [*] button followed by the number or symbol above the
gray command. For example, to place a [+] on the command line, press [*] [1].
Pressing [*] will clear the command. Commands entered from the phone remote will appear on the
command line for the console.
Phone Remote Connector
The pin outs for the phone remote RJ11 connector are:
• Pin 4 - Data+
• Pin 5 - Data-
