Appendix C
Display Conventions
Element relies on many traditional ETC indicators with which you may be familiar, as well as some
new ones. This section identifies the graphical and colorful conventions used in Element to indicate
conditions to you.
Indicators in the Live/Blind Display
This is the live/blind summary view.
Note:
The color and text conventions described below apply regardless of the format of
live/blind being used. See “Using [Format]” on page 24.
8- Green 9- Magenta7- Blue 6- Red
10- White 11- Yellow1- Gray Number
2- White Number 3- Bright White Number
4- Gold Outline 5- No Outline
