ETC Lighting Control Console - Page 279

F Remote Control 267
Technical Specifications
Handheld Transmitter
Base Station Receiver
Output U.S.A. - Default HF:1 (2.410 MHz) with 11
additional HF: channels available (2.410 - 2.465
GHz). 99 groups available per channel.
Antenna
- Helical, fixed.
Connections
- Integral USB Mini-B connector for
charging the unit.
Working range
- 90m (300 ft) indoor, 200m (656
ft) in free field.
Power - 2x NiMH rechargeable battery. (Recharge
using the USB connection.)
Size
- 160mm(4.5”) x 72mm (2.6”) x 20mm (.8”)
excludes antenna.
Weight
- 400g (14 oz.) includes antenna.
Data
- USB type B. Ethernet.
Connections
- Integral USB connector to console
or RPU. Ethernet 802.3af.
Power
- USB or Power over Ethernet (PoE).
Maximum USB cable length
- 5m (16.5’) from
power source using USB.
Size
- 112mm(4.4”) x 71mm (2.7”) x 45mm (.7”)
excludes antenna.
Weight
- 380g (13 oz.) includes antenna.
