ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter E: Appendixes
Operation & Software Manual
Direct Drives & Systems 317
DSC2P and DSC2V monitorings
94 Error auxiliary channel second command Macro
95 Error auxiliary channel Macro aux 2
96 Error auxiliary channel Macro aux 3
97 Error auxiliary channel Macro aux 4
100 Optional board error 100. See optional board manual
101 Optional board error 101. See optional board manual
102 Optional board error 102. See optional board manual
103 Optional board error 103. See optional board manual
104 Optional board error 104. See optional board manual
105 Optional board error 105. See optional board manual
106 Optional board error 106. See optional board manual
107 Optional board error 107. See optional board manual
108 Optional board error 108. See optional board manual
109 Optional board error 109. See optional board manual
110 Optional board error 110. See optional board manual
111 Optional board error 111. See optional board manual
112 Optional board error 112. See optional board manual
113 Optional board error 113. See optional board manual
114 Optional board error 114. See optional board manual
115 Optional board error 115. See optional board manual
116
This error is generated by the ERR command. In
general, this command is sent by the DSMAX or the
u-master
130
Hardware overcurrent. The current has reached the
maximum admissible value by the controller
141 Watchdog error
144
The difference between the oscillator and quartz is too
big
150 Bad measure during the phasing process when K90=1
151
Bad time measurement during phasing process when
K90=1
152
Error when the controller is disabled during
phasing process when K90 = 1 or 2
153 Too low force when K90=6
154 Too high force when K90=6
155 Too low time when K90=6
156 Time-out during AUT command
157 Error during the phasing process when K90=2
190
The controller has executed a save operation (SAV
command)
M66 Gives the warning code 0 0 255
1 This warning occurs when M67 is greater than K85/2
2
This warning occurs when the temperature of the
controller is greater than 60°C
M Alias Values
Bit #
<P1>
Comment for monitorings M
and <P1> of the DSC2P and DSC2V
Def. Val
<P1>
Min. Val
<P1>
Max. Val
<P1>
