DSCDP monitorings
60
Error in homing process when leaving home switch or
limit switch. Checks K48 parameter or DIN 2, 9 or 10.
This error occurs when after the trip from K48 the home
switch or limit switch is present
61
Error in multi-index homing process. Checks K43, K44
and K75 parameters. This error occurs when the motor
has reached the two mechanical end stops (detections
are done by K43 and K44) without having finished the
homing process (for linear motors)
62
Error in single index homing process. Checks K43 and
K44 parameters. This error occurs when the motor has
reached the two mechanical end stops (detections are
done by K43 and K44) without having finished the
homing process (for linear motors)
63 Error in start synchro on input (STI command)
65
Error when the real position (M7) is out of the limits
defined by K34 and K35 when bit#1 of K36 is set
66
Error when the reference position is out of the limits
defined by K34 and K35 when bit#2 of K36 is set
67
Movement not possible because the controller is not in
power on mode
68
PWR ON not possible because the controller is in
interpolation mode (by ITP=1)
69
Homing is not possible due to the configuration of the
controller and the setting
80 Framing error on EBL2
81 Overrun error on EBL2
82 Checksum error on EBL2 message
84 Input buffer full on EBL2
85 Bad CRC on EBL2 in received message in CRC Mode
88 Other axis error on EBL2
89 Overrun error with Macro
90 Violation error with Macro
91 Parity error with Macro
92 Underrun error with Macro
93 Synchro error with Macro
94 Error auxiliary channel second command Macro
95 Error auxiliary channel Macro aux 2
96 Error auxiliary channel Macro aux 3
97 Error auxiliary channel Macro aux 4
100 Optional board error 100. See optional board manual
101 Optional board error 101. See optional board manual
102 Optional board error 102. See optional board manual
103 Optional board error 103. See optional board manual
104 Optional board error 104. See optional board manual
105 Optional board error 105. See optional board manual
106 Optional board error 106. See optional board manual
107 Optional board error 107. See optional board manual
108 Optional board error 108. See optional board manual
109 Optional board error 109. See optional board manual
M Alias Values
Bit #
<P1>
Comment for monitorings M
and <P1> of the DSCDP
Def. Val
<P1>
Min. Val
<P1>
Max. Val
<P1>
