Etel DSC2P - Page 325

ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter E: Appendixes
Operation & Software Manual
Direct Drives & Systems 325
DSCDP monitorings
110 Optional board error 110. See optional board manual
111 Optional board error 111. See optional board manual
112 Optional board error 112. See optional board manual
113 Optional board error 113. See optional board manual
114 Optional board error 114. See optional board manual
115 Optional board error 115. See optional board manual
116
This error is generated by the ERR command. In
general, this command is sent by the DSMAX or the
u-master
130
Hardware overcurrent. The current has reached the
maximum admissible value by the controller
141 Watchdog error
144
The difference between the oscillator and quartz is too
big
150 Bad measure during the phasing process when K90=1
151
Bad time measurement during phasing process when
K90=1
152
Error when the controller is disabled during phasing
process when K90 = 1 or 2
153 Too low force when K90=6
154 Too high force when K90=6
155 Too low time when K90=6
156 Time-out during AUT command
157 Error during the phasing process when K90=2
190
The controller has executed a save operation (SAV com-
mand)
M66 Gives the warning code 0 0 255
1 This warning occurs when M67 is greater than K85/2
2
This warning occurs when the temperature of the
controller is greater than 60°C
3
Power supply inrush or power voltage too low (for rack
version, it occurs when inrush signal on d14 of JC15 is
not at 0V. This signal is given by ETEL's power supply or
must be given by the user in case of another power
supply)
5
This warning occurs when the amplitude of the analog
encoder signals are too small (2x the error)
6
This warning occurs when the tracking error is greater
than K30/2
8 Wrong value coming from the digital Hall sensor
9
Loss of synchronization between the TEB signal and the
controller interrupt
11
This warning occurs when the power voltage is greater
than 425V and no motor in Power On
M67
Current loop i2t value. When M67 is greater than K85,
the controller generates an I2T error (M64=4)
0 0 2147483647
M70 Indicates the type of controller 7 7 7
M Alias Values
Bit #
<P1>
Comment for monitorings M
and <P1> of the DSCDP
Def. Val
<P1>
Min. Val
<P1>
Max. Val
<P1>
