DSCDL monitorings
106 Optional board error 106. See optional board manual
107 Optional board error 107. See optional board manual
108 Optional board error 108. See optional board manual
109 Optional board error 109. See optional board manual
110 Optional board error 110. See optional board manual
111 Optional board error 111. See optional board manual
112 Optional board error 112. See optional board manual
113 Optional board error 113. See optional board manual
114 Optional board error 114. See optional board manual
115 Optional board error 115. See optional board manual
116
This error is generated by the ERR command. In
general, this command is sent by the DSMAX or the
u-master
130
Hardware overcurrent. The current has reached the
maximum admissible value by the controller
131 Error on the power bridge
141 Watchdog error
144
The difference between the oscillator and quartz is too
big
152
Error when the controller is disabled during phasing
process when K90 = 2
153 Too low force when K90=6
154 Too high force when K90=6
155 Too low time when K90=6
156 Time-out during AUT command
157 Error during the phasing process when K90=2
190
The controller has executed a save operation (SAV
command)
M66 Gives the warning code 0 0 255
1 This warning occurs when M67 is greater than K85/2
2
This warning occurs when the temperature of the
controller is greater than 60°C
4
This warning occurs when the power voltage (Vpower) in
volt is greater than K148/100
5
This warning occurs when the amplitude of the analog
encoder signals are too small (2x the error)
6
This warning occurs when the tracking error is greater
than K30/2
9
Loss of synchronization between the TEB signal and the
controller interrupt
10
This warning occurs when the power voltage (Vpower) in
volt is lower than K146/100
M67
Current loop i2t value. When M67 is greater than K85,
the controller generates an I2T error (M64=4)
0 0 2147483647
M70 Indicates the type of controller 8 8 8
M71
Gives the software boot version of the controller. A
special ETEL procedure allows the conversion of this
value in the software boot version (format is the same
than M72)
0 0 4294967295
M Alias Values
Bit #
<P1>
Comment for monitorings M
and <P1> of the DSCDL
Def. Val
<P1>
Min. Val
<P1>
Max. Val
<P1>
