PhoenixBIOS features and setup
Issue G 61
Field Explanation
Small LBA-Disk
CHS Translation
Determines whether CHS translation is made for LBA-capable
hard disks with less than 1024 cylinders.
You can choose either Yes (translate CHS for all LBA-capable
disks) or No (translate CHS only if the hard disk drive has more
than 1024 cylinders).
Try changing this if you have problems booting from a
CompactFlash
®
.
Enable memory gap
Used to free up address space for use with an option card.
Choose Enabled to create a 1MB extended memory gap in the
system RAM, starting at 15MB.
I/O Device
Configuration
Displays a sub-menu containing options you can use to set up
Input/Output ports. See page 62
for details.
Keyboard Features
Displays a sub-menu containing options you can use to control
aspects of how the keyboard works. See page 68
for details.
Cache Memory
Displays a sub-menu containing options you can use to specify
cache memory settings. See page 69
for details.
PCI Configuration
Displays a sub-menu containing options you can use to configure
PCI devices. See page 70
for details.
CPU Control Sub-
Menu
Displays a sub-menu containing options you can use to control
how the CPU operates. See page 73
for details.
MCH Control Sub-
Menu
Displays a sub-menu containing options you can use to control
how the Memory Controller Hub operates. See page 75
for
details.
Video (Intel IGD)
Control Sub-Menu
Displays a sub-menu containing options you can use to configure
the Internal Graphics Device. See page 76
for details.
ACPI Control Sub-
Menu
Displays a sub-menu containing options you can use to configure
ACPI settings. See page 78
for details.
Hardware Monitor
Displays a sub-menu where you can view details of system
hardware temperature and voltages, as well as controlling the
system and CPU fans. See page 79
for details.
