NOTE:
Push the packing stop [d] to the level of the tapered part of the packing [c] when
putting them together. The nut [b] cannot be attached if the packing stop is pushed in
too little or too much.
When pushing the packing stop [d] in, make sure that the slit part of packing [c] and
that of packing stopper [d] are diametrically opposite to each other. If the packing [c]slit
is not coveredby the packing stop [d], water resistance cannot be guaranteed.
6.
Tighten the nut [b].
7.
Close the lid and install the lid locking latches (2).
24
