Evinrude E-tec 2011 Series - Icon Rigging Kit Selection Chart

45
EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON RIGGING KIT SELECTION CHART
Step 1: Select number of engines.
12345
Step 2: Select appropriate remote control.
Concealed
Side Mount
Single Lever
Binnacle Mount
Dual Lever Binnacle Mount
Step 3: Order P/N for main or single station
rigging kit.
Rigging Kit
P/N 764990
Rigging Kit
P/N 764980
Rigging Kit
P/N 764982
Rigging Kit
P/N 764984
Rigging Kit
P/N 764986
Rigging Kit
P/N 764988
Main Station Rigging Kits include:
ICON Remote Control, P/N 765412 765381 765382 765383 765384 765385
Master Power/Key Switch, P/N 765371 765373 765374 765371 765371 765371
Start/Stop Switch Panel, P/N 765378 – 765375 765376 765377
Trim Switch Panel, P/N – 765388 765389 765390
Network Power Cable, P/N 764921
ICON Gateway Module Kit, P/N 764922
ICON Accessory Power Relay, P/N 765296
ICON Hubs (2), P/N 764943
Buss Cable Extension 15ft (4.57m), P/N
(Kit includes 1 buss cable per engine)
764948
Buss Cable Backbone 20ft (6.1m), P/N 764950 –
Buss Cable Backbone 25ft (7.4m), P/N – 764951
Engine Identity Plug ID#1, P/N – 764916
Engine Identity Plug ID#2, P/N – 764917
Engine Identity Plug ID#3, P/N – 764918
Engine Identity Plug ID#4, P/N – 764919
ICON Remote Control User’s Guide 765410 764954
Installation Instructions included:
ICON Remote Controls, P/N 355248 355084
ICON Switch Panels, P/N 355085 355085
ICON Gateway Module & Cable Kit, P/N 355086 355086
ICON Accessory Power Relay Kit, P/N 355087 355087
ICON Quick Connect Guide, P/N 765409 764953
