1.5 XT[2] SERVER MAIN SPECIFICATIONS
1.5.1 VIDEO
XT[2] Server
Standard Definition High Definition
Video Formats 525i 59.94fps (NTSC)
625i 60fps (PAL)
720p 50/59.94fps
1080i 50/59.94fps
Digital Interface 10-bit 4:2:2 Serial (SMPTE259M).
Full frame synchronizer at input.
Dual output for PLAY channels.
10-bit 4:2:2 Serial (SMPTE292M).
Full frame synchronizer at input.
Dual output for PLAY channels.
Number of channels
(6RU rack)
2, 4 or 6 channels,
reversible REC/PLAY
2, 4 or 6 channels,
reversible REC/PLAY
Number of channels
(4RU rack)
2 or 4 channels,
reversible REC/PLAY
2 or 4 channels,
reversible REC/PLAY
Monitoring & Down-
converters
1 CVBS or SDI (software select)
per channel, with OSD
1 built-in down-converter per
channel, CVBS or SDI output
(software select) with OSD +
additional clean SDI output.
1 dedicated HD SDI output with
OSD per channel
Reference Analogue Black Burst Analogue Black Burst and HD Tri-
Level Sync
Graphics Board n.a. n.a.
1.5.2 AUDIO
• up to 8+8 analogue balanced input & output channels
• up to 16+16 (8 pairs + 8 pairs) AES/EBU or Dolby E input & output
channels
• up to 48 channels embedded audio (8 audio per video)
• 4 additional analogue balanced output channels for monitoring
• all audio connectors on mainframe
