EVS XT2 - Starting Xnet

XT Series DISK RECORDER - Version 9.00 - Hardware Technical Reference Manual
EVS Broadcast Equipment SA – April 2008
Issue 5.00
31
a. Stratos Lightwave Media Converter TX/RX VMC-T-H-2/VMC-R-H-2
(www.stratoslightwave.com)
b. Telecast TX/RX292 (www.telecast-fiber.com)
c. Network Electronics SDI-EO-13T (electrical to optical) / SDI-OE-S
(optical to electrical) (www.network-electronics.com)
d. Network Electronics HD-EO-13T (electrical to optical / HD-OE
(optical to electrical)
e. BlueBell BB320T (TX) and BB320R (RX) (www.bluebell.tv)
Cable type @ 1485 Mbps @ 540 Mbps
RG59 45m / 148ft 100m / 328ft
RG6 90m / 484ft 180m / 590ft
RG11 120m / 393ft 250m / 820ft
Super HiQ 150m / 492ft 350m / 1148ft
Fiber 80km(*) 200km(*)
(*) 80km/200km is the total length of the return path, i.e. the actual
distances between the 2 servers connected via the fiber link is half of this
value, i.e. 40 km @ 1485Mbps, 100 km @ 540Mbps.
Note
When reclockers are used, the total delay induced by these
reclockers between 2 active servers on the network may not
exceed 15μs.
2.8.4 STARTING XNET
1. When all above conditions are fulfilled, turn on all “Masters” and
“Clients” XTs, and make sure the Multicam application is started on all
of them. A message appears because they are looking for the “Server”
XT.
2. Turn on the “Server” XT and start the Multicam application. The other
XTs should see the “Server” arriving on the network and will connect
automatically. Connection takes a few seconds (usually between 2 and 5
sec) for each XT.
