3.3 AUDIO CODEC BOARD
The AUDIO CODEC board is the audio interface between the COHX
boards and the HCTX board. VIDEO CODEC and AUDIO CODEC board
are tied to the HCTX board with one Bus connector on the front side.
Different audio configurations are available with the AUDIO CODEC
board. See Audio configurations in chapter 2 for details.
AES/EBU
ANALOG
3.3.1.1 LED INFORMATION AND CONNECTOR
LD 1-3: Internal EVS information only
LD4: transfer activity to/from the HCTX board
