1.5.5 SUPPORTED SMPTE STANDARDS
The following standards are supported:
SD SDI
SMPTE 259M (525i 625i)
HD SDI
SMPTE 292M (720p 50 and
59.94 ; 1080i 50 and 59.94)
Embedded audio HD SMPTE 299M
AES/EBU audio SMPTE 272M
LTC SMPTE 12M
D-VITC SMPTE 266M
Ancillary TC in HD RP 188
Vertical Ancillary Data SMPTE 334M
VC-3 SMPTE 2019-1
IMX D-10 SMPTE 356M
1.5.6 MAXIMUM BITRATE VALUES
Those maximum values are valid for XT[2] servers running Multicam
version 08.00.xx or higher. They guarantee a smooth play and a browse
at 100% speed on all channels simultaneously.
2 ch 4 ch 6 ch
PAL
100 100 100
SD JPEG
NTSC
100 100 100
PAL
225 225 160
HD JPEG
NTSC
250 250 160
PAL
225 225 160
HD MPEG
NTSC
250 250 160
PAL
185 185 120
Avid DNxHD®
NTSC
220 220 145
PAL
185 185 120
Apple ProRes 422
NTSC
220 220 145
