3.4 RAID CONTROLLER BOARDS
3.4.1 HCTX BOARD
The HCTX board is actually divided in 4 parts (3 in front, 1 in the back).
• Front left : GBE module
• Front centre : CTL controller module
• Front right : SDTI XNet[2] module
• Back : CPU module
