EVS XT2 - TTL TTL Inputs on the XT Server (GPI Input 5, 6, 7, 8); GPI out Settings

XT Series DISK RECORDER – Version 9 - Hardware Technical ReferenceIssue 5.00
EVS Broadcast Equipment SA – April 2008
22
2.3.3 TTL Æ TTL INPUTS ON THE XT SERVER (GPI INPUT
5, 6, 7, 8)
12
3
4
5
678910
11
12
13
141516171819202122232425
IN
+
G
P
I 4
G
r
o
u
n
d
IN
+
G
P
I 3
IN
+
G
P
I 2
IN
+
G
P
I 1
IN
+
G
P
I 7
IN
+
G
P
I 6
IN
+
G
P
I 5
TTL 1
TTL 2
TTL 3
TTL 4
Common Ground
IN
+
G
P
I 8
Each TTL input on the DB25 is directly connected to the pin of the TTL
connector on the device triggering the GPI. The ground must be common
between the DB25 connector of the XT and the external device.
2.4 GPI OUT SETTINGS
The user can define the functions, types and settings associated to the
GPI outs in the following applications:
• Setup menu of the Remote Panel (pages 8.3 & 8.4)
• IP Director settings (GPI and Auxiliary Track tab)
