EVS XT2 - Leds on the COHX Base Module with Genlock; Leds on the COD a and COD B Modules (from Left to Right)

XT Series DISK RECORDER – Version 9 - Hardware Technical ReferenceIssue 5.00
EVS Broadcast Equipment SA – April 2008
40
3.2.1.2 LEDS ON THE COHX BASE MODULE WITH GENLOCK
GLK
Off when the genlock module is not initialized
Blinks green when the genlock module is properly initialized, but not
valid genlock signal is detected
On, steady
green
when the module is initialized and a valid genlock signal
is detected
Red
(intermittent)
when there is a genlock problem
Red (steady) when a resync is needed
PSU OK
On (green) when all voltages are present and in the allowed range,
otherwise the led is off
3.2.1.3 LEDS ON THE COD A AND COD B MODULES (FROM LEFT
TO RIGHT
)
CPU
Blinks green to indicate CPU activity
On, steady
green
when there is a problem with the processor of the COD
module
PLAY
On (green) when the COD module is set by the software in play mode
Off when the COD module is set in record mode
PVID
on (green) when a valid video signal has been detected on the J8
connector (SD/HD SDI input), whether the COD module is
in play or record mode
TF (transfer)
Blinks green while data transfers occur between the COD module and
the HCTX board
M1, M2,
M3, M4
not yet used
