3. Hardware Description
3.1 BOARDS AND SLOT
CONFIGURATIONS
The EVS Disk Recorder contains all the EVS developed boards. Several
board configurations are available.
3.1.1 6U FRAME
Slot
XT[2] SD, HD or HD/SD
#
9 Disk Array
8 HCTX
7 CODA (Audio Codec)
6 (empty)
5 COHX (SD, HD or SD/HD) #3
4 COHX (SD, HD or SD/HD) #2
3 (empty)
2
COHX (SD, HD or SD/HD) #1
Genlock
1 MTPC
3.1.2 4U FRAME
Slot
XT[2] SD, HD or HD/SD
#
6 Disk Array
5 HCTX
4 CODA (Audio Codec)
3 COHX (SD, HD or SD/HD) #2
2
COHX (SD, HD or SD/HD) #1
Genlock
1 MTPC
