Calculation:
Maximum SDTI bandwidth / Actual Bandwith = real time transfers:
110MB/s / 18.4MB/s = 6 real time transfers.
Note: This number is the maximum that the network connection can
support. Of course it is also necessary that the XT[2] where the material
is stored has enough local disk bandwidth to feed the network accesses,
on top of its own local channels (cfr point 4. Max. RT Channels)
AVID DNXHD® & APPLE PRORES 422 AT 50HZ (“PAL”)
Codec XT[2] Storage Capacity XFile Storage Capacity
Video
Bitrate
Fields
/Block
Actual
Bandwidth
Max. RT
Channels
5x73GB 5x146GB 5x300GB 250GB 500GB 750GB
Avid
DNxHD®
85 Mbps 35 11.43 MB/s 13.13 6.57h 13.34h 27.62h 5.60h 11.40h 17.19h
Avid
DNxHD®
100 Mbps 30 13.33 MB/s 11.25 5.63h 11.44h 23.68h 4.80h 9.77h 14.73h
Avid
DNxHD®
Apple ProRes
422
120 Mbps 26 15.38 MB/s 9.75 4.88h 9.91h 20.52h 4.16h 8.47h 12.77h
Avid
DNxHD®
Apple ProRes
422 HQ
185 Mbps 17 23.53 MB/s 6.38 3.19h 6.48h 13.42h 2.72h 5.53h 8.35h
AVID DNXHD® & APPLE PRORES 422 AT 150HZ (“PAL
SUPER MOTION 3X”)
Codec XT[2] Storage Capacity XFile Storage Capacity
Video
Bitrate
Fields
/Block
Actual
Bandwidth
Max. RT
Channels
5x73GB 5x146GB 5x300GB 250GB 500GB 750GB
Avid
DNxHD®
85 Mbps 12 33.33 MB/s 4.50 2.25h 4.57h 9.47h 1.92h 3.91h 5.89h
Avid
DNxHD®
100 Mbps 10 40.00 MB/s 3.75 1.88h 3.81h 7.89h 1.60h 3.26h 4.91h
Avid
DNxHD®
Apple ProRes
422
120 Mbps 9 44.44 MB/s 3.38 1.69h 3.43h 7.10h 1.44h 2.93h 4.42h
Avid
DNxHD®
Apple ProRes
422 HQ
185 Mbps 5 66.67 MB/s 2.25 1.13h 2.29h 4.74h 0.96h 1.95h 2.95h
