EWM SATURN MIG 300 PROGRAM - Technical Data

3 Technical Data
3/1
3.1 Saturn -Series
Saturn - Series
MIG 200 MIG 250 MIG 300
Welding Current Range
30 - 200 A 30 - 250 A 30 - 300 A
Welding Voltage MIG
15 - 24 V 15 - 26,5 V 15 - 29 V
max. Welding Current at
30% Duty Cycle
200 A 250 A 300 A
max. Welding Current at
60% Duty Cycle
140 A 175 A 210 A
max. Welding Current at
100% Duty Cycle
110 A 135 A 165 A
Open Circuit voltage
15 V - 36 V 15,5 V - 37,5 V 15,5 V - 41 V
Mains fuses - slow acting
3 x 16 A 3 x 16 A 3 x 20 A
Switch Steps
12 15
Load cycle time
10 min
Mains Voltage
3 x 400 V / 415V (bei 50/60Hz)
max. Connected Power
7,1 kVA 9,6 kVA 12,8 kVA
Frequency
50/60 Hz
Wire-feed speed (compact)
1 m/min- 20 m/min
Work-piece Cable
35 mm
2
50 mm
2
Ambient Temperature
-10°C - +40°C
Unit Cooling
Fan
Torch Cooling
Air
Euro central connection
ja
Insulation Class
H
Protection Type
IP 23
Dimensions without gas
cylinders with cylinder holder
L/W/H
920 mm / 460 mm / 745 mm
Weight without accessories 93 Kg 102 Kg 112 Kg
