8 Commissioning
8/2
8.3 Cooling the Welding Machine
To achieve the optimum duty cycle from the power components, pay attention to the following
conditions:
• Ensure that the workplace is adequately ventilated,
• The air inlets and outlets of the machine must be unobstructed,
• Metal particles, dust or other fine bodies may not gain access to the unit.
8.4 Welding Torch Connections
We can only guarantee the perfect function of our machines when they are used with our
range of welding torches.
8.4.1 MIG- Welding Torch
Welding torch with guide spiral:
The capillary tube must be in place in the central connection!
Welding torch with guide spiral (e.g. with Teflon guide):
No capillary tube may be present in the central connection!
Preparing the welding torch for the welding task:
• Shorten the Teflon liner and the push on guide tube just enough that the gap to the drive rollers
is as short as possible.
The Teflon liner and the guide tube may not be deformed!
• Debur the Teflon guide tube and liner cleanly!
Connecting the welding torch:
• Insert the welding torch in the welding machine central connection and screw tight with the cap
nut.
8.4.2 MIG- Welding Torch with adjustment knob for wire-feed correction
in working
