4 Description of the System components
4/8
4.5.2 Hand Remote Control on the Welding Torch (Option)
in working
4.6 The Interfaces (Option, only with the M201)
4.6.1 Automation Interface(Option, only for the M201)
The welding power source is characterised by a very high standard of safety.
This high safety standard is also retained when the machine is used with peripheral equipment for
mechanised welding, if this peripheral equipment also meets the same criteria, especially with respect
to insulation and power supply.
This is guaranteed when using transformers to VDE 0551.
All the interface contacts described below in this chapter may be exposed to a maximum
load of: 100mA +15V/-15V
The following signals are available at the remote control socket:
• Start / Stop - Power Source
• Current is flowing - Signal I > 0
• Pilot voltage for the wire feed speed
