TLP Pro x25 Series and TLS x25 Series • Installation Overview 8
3. Mount and cable the units:
ATTENTION:
• Do not power on the touchpanels or control processors until you have read the ATTENTION about
Power over Ethernet (PoE) power supplies (see page 15).
• Ne branchez pas les écrans tactiles ou les processeurs de contrôle avant d’avoir lu la mise en
garde sur les sources d’alimentation via Ethernet (PoE) (voir page 15).
• Mount the units.
NOTES:
• If you use the setup menu to configure the TLP Pro 525M, 725M, or 1025M for network
communication (see step 4, below), configure the touchpanel before mounting as you will need
access to the rear panel Menu button.
• The TLS models do not use the setup menu.
• Connect cables to the touchpanels (see TLP Pro 525T, TLP Pro 725T, and TLP Pro 1025T Base on
page 13 or Rear Panel Features on page 11).
• Connect the power cords and power on all devices (see figure 4,
F
, on page 11 or figure 5,
F
, on
page 13).
4. Set up the touchpanels for network communication:
• Connect the PC that you are using for setup, the Extron control processor (not required for TLS models),
and the touchpanel to the same Ethernet subnetwork.
• For TLP models, use the On-screen Menus on page 16 or Toolbelt to set the DHCP status and, if
required, the IP address, subnet mask, gateway, and related settings for the touchpanel.
• For TLS models, use the Network settings of Room Agent to set the DHCP status and, if required, the IP
address, subnet mask, gateway, and related settings for the touchpanel.
5. Configure or program the Touchpanels
• For TLS touchpanels, the Room Agent Help File provides step-by-step instructions and detailed
information.
• For TLP Pro touchpanels, the GUI Designer Help File, the Global Configurator Plus and Professional Help
File, the ControlScript Deployment Utility Help File, and the Toolbelt Help File provide step-by-step
instructions and detailed information.
• The Global Configurator Help File also includes an introduction to that software and sections on how
to start a project and configuration.
• ControlScript Deployment Utility provides an Extron-exclusive Python library, including Extron
ControlScript Extension for VS Code. See the ControlScript Deployment Utility Help File for more
information.
NOTE: Frequently touched devices, such as touchscreens, require regular cleaning to ensure their surfaces
remain sanitary. Plastic surfaces and cosmetic finishes can be damaged by long term exposure to
chemicals. For Best Practices for Cleaning Your Extron Products on page 36.
