Extron electronics XTP II CrossPoint Series User Manual

SIS Command and Response Table for Input-Endpoint-Specific Commands (continued)
Command Function
SIS Command
(Host to Unit to Endpoint)
Response
(Endpoint to Unit to Host)
Additional Description
XTP T VGA transmitter specific commands (continued)
Color
NOTE: Color adjustments are available for RGBcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite video
inputs.
Set a specific color value
E
I
X^
*
X3@
COLR
}
ColrI
X^
*
X3@]
Specify the color adjustment.
Increment color value
E
I
X^
+COLR
}
ColrI
X^
*
X3@]
Increase the color setting by one.
Decrement color value
E
I
X^
–COLR
}
ColrI
X^
*
X3@]
Decrease the color setting by one.
View the color value
E
I
X^
COLR
} X3@]
Show the color setting.
Tint
NOTE: Tint adjustments are available for NTSC S-video, and NTSC composite video inputs.
Set a specific tint value
E
I
X^
*
X3@
TINT
}
TintI
X^
*
X3@]
Specify the tint adjustment.
Increment tint value
E
I
X^
+TINT
}
TintI
X^
*
X3@]
Increase the tint setting by one.
Decrement tint value
E
I
X^
–TINT
}
TintI
X^
*
X3@]
Decrease the tint setting by one.
View the tint value
E
I
X^
TINT
} X3@]
Show the tint setting.
Brightness
NOTE: Brightness adjustments are available for RGBcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite
video inputs.
Set a specific brightness value
E
I
X^
*
X3@
BRIT
}
BritI
X^
*
X3@]
Specify the brightness adjustment.
Increment brightness value
E
I
X^
+BRIT
}
BritI
X^
*
X3@]
Increase the brightness setting by one.
Decrement brightness value
E
I
X^
–BRIT
}
BritI
X^
*
X3@]
Decrease the brightness setting by one.
View the brightness value
E
I
X^
BRIT
} X3@]
Show the brightness setting.
Contrast
NOTE: Contrast adjustments are available for RGBcvS (SCART), interlaced component video (YUVi), S-video, and NTSC composite
video inputs.
Set a specific contrast value
E
I
X^
*
X3@
CONT
}
ContI
X^
*
X3@]
Specify the contrast adjustment.
Increment contrast value
E
I
X^
+CONT
}
ContI
X^
*
X3@]
Increase the contrast setting by one.
Decrement contrast value
E
I
X^
–CONT
}
ContI
X^
*
X3@]
Decrease the contrast setting by one.
View the contrast value
E
I
X^
CONT
} X3@]
Show the contrast setting.
Pixel phase
NOTE: Pixel phase adjustments are available for RGBHV and non-interlaced component video (YUVp) video inputs.
Set a specific pixel sampling phase
E
I
X^
*
X3@
PHAS
}
PhasI
X^
*
X3@]
Specify the pixel sampling phase.
Increment sampling value
E
I
X^
+PHAS
}
PhasI
X^
*
X3@]
Increase the phase value.
Decrement sampling value
E
I
X^
–PHAS
}
PhasI
X^
*
X3@]
Decrease the phase value.
View the sampling value
E
I
X^
PHAS
} X3@]
Show the pixel sampling phase.
NOTE: X^ = Input number (for other than tie) 01 – 16, 32, or 64
X3@ = Picture adjustments 000 through 255 (128 = default)
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 99
