Extron electronics XTP II CrossPoint Series User Manual

D
Preset button — The Preset button has two primary functions (❏) and three
secondary functions (•):
❏ Activates Save Preset mode to save a configuration as a preset and Recall Preset
mode to activate a previously-defined preset.
❏ Blinks when Save Preset mode is active and lights steadily when Recall Preset
mode is active.
• With the Enter, View, and Esc buttons, selects Serial Port Configuration mode.
• Selects 19200 baud for the rear panel Remote port in Serial Port Configuration
mode and indicates the selection.
• With the View and Esc buttons, selects front panel security Lock mode 2 or
toggles between mode 0 (unlocked) and mode 2.
E
View (
<
) button — The View (
<
) button has one primary function (❏) and six secondary
functions (•):
❏ Select and indicate View-only mode, which displays the current configuration.
NOTE: View-only mode also provides a way to mute and unmute the outputs.
• Decreases the audio level of the selected analog input.
• Decreases the volume of the selected analog output.
• With the Enter, Preset, and Esc buttons, selects Serial Port Configuration mode.
• Selects 38400 baud for the rear panel Remote port in Serial Port Configuration
mode, and indicates the selection.
• With the Preset button and Esc button, selects between front panel locks
(Lock mode 2 and Lock mode 0).
• With the Esc button, selects between front panel locks (Lock mode 2 and
Lock mode 1).
F
Esc (
>
) button — The Esc (
>
) button has two primary functions (❏) and six secondary
functions (•):
❏ Cancels operations or selections in progress and resets the front panel button
indicators.
❏ Blinks once to indicate that the escape function has been activated.
• Increases the audio level of the selected analog input.
• Increases the volume of the selected analog output.
• With the Enter, Preset, and View buttons, selects Serial Port Configuration
mode.
• Selects 115200 baud for the rear panel Remote port in Serial Port Configuration
mode and indicates the selection.
• With the Preset button and View button, selects between front panel locks
(Lock mode 2 and Lock mode 0).
• With the View button, selects between front panel locks (Lock mode 2 and
Lock mode 1).
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Operation 35
