DVI – PC values (continued)
099 067 051
1280x768 @ 50 Hz
107 075 059
1366x768 @ 50 Hz
115 083 067
1600x1200 @ 50 Hz
123 091 075
2048x1080 @ 50 Hz
100 068 052
1280x768 @ 60 Hz
108 076 060
1366x768 @ 60 Hz
116 084 068
1600x1200 @ 60 Hz
124 092 076
2048x1080 @ 60 Hz
101 069 053
1280x800 @ 50 Hz
109 077 061
1400x1050 @ 50 Hz
117 085 069
1680x1050 @ 50 Hz
102 070 054
1280x800 @ 60 Hz
110 078 062
1400x1050 @ 60 Hz
118 086 070
1680x1050 @ 60 Hz
HDMI – PC values, all with 2-channel embedded audio
125 093 077
1024x768 @ 50 Hz
132 100 084
1280x1024 @ 60 Hz
139 107 091
1440x900 @ 50 Hz
146 114 098
1680x1050 @ 60 Hz
126 094 078
1024x768 @ 60 Hz
133 101 085
1360x768 @ 50 Hz
140 108 092
1440x900 @ 60 Hz
147 115 099
1920x1200 @ 50 Hz
127 095 079
1280x768 @ 50 Hz
134 102 086
1360x768 @ 60 Hz
141 109 093
1600x900 @ 50 Hz
148 116 100
1920x1200 @ 60 Hz
128 096 080
1280x768 @ 60 Hz
135 103 087
1366x768 @ 50 Hz
142 110 094
1600x900 @ 60 Hz
149 117 101
2048x1080 @ 50 Hz
129 097 081
1280x800 @ 50 Hz
136 104 088
1366x768 @ 60 Hz
143 111 095
1600x1200 @ 50 Hz
150 118 102
2048x1080 @ 60 Hz
130 098 082
1280x800 @ 60 Hz
137 105 089
1400x1050 @ 50 Hz
144 112 096
1600x1200 @ 60 Hz
131 099 083
1280x1024 @ 50 Hz
138 106 090
1400x1050 @ 60 Hz
145 113 097
1680x1050 @ 50 Hz
HDMI – HDTV values
151 119 103
480p @ 60 Hz 2-channel audio
155 123 107
720p @ 50 Hz multi-channel audio
159 127 111
1080i @ 50 Hz multi-channel audio
163 131 115
1080p @ 50 Hz multi-channel audio
152 120 104
576p @ 50 Hz 2-channel audio
156 124 108
720p @ 60 Hz multi-channel audio
160 128 112
1080i @ 60 Hz multi-channel audio
164 132 116
1080p @ 60 Hz multi-channel audio
153 121 105
720p @ 50 Hz 2-channel audio
157 125 109
1080i @ 50 Hz 2-channel audio
161 129 113
1080p@ 50 Hz 2-channel audio
154
†
122
†
106
†
720p @ 60 Hz 2-channel audio
158 126 110
1080i @ 60 Hz 2-channel audio
162 130 114
1080p @ 60 Hz
2-channel audio
User – Assigned EDIDs
165 133 117
User 1
167 135 119
User 3
169 137 121
User 5
171 139 123
User 7
166 134 118
User 2
168 136 120
User 4
170 138 122
User 6
172 140 124
User 8
†
Default value, digital
Table 9. EDID Values (continued)
User – Assigned EDIDs 9 through 64 (XTP II CrossPoint 6400 only)
173
User 9
179
User 15
185
User 21
191
User 27
197
User 33
203
User 39
209
User 45
215
User 51
221
User 57
227
User 63
174
User 10
180
User 16
186
User 22
192
User 28
198
User 34
204
User 40
210
User 46
216
User 52
222
User 58
228
User 64
175
User 11
181
User 17
187
User 23
193
User 29
199
User 35
205
User 41
211
User 47
217
User 53
223
User 59
176
User 12
182
User 18
188
User 24
194
User 30
200
User 36
206
User 42
212
User 48
218
User 54
224
User 60
177
User 13
183
User 19
189
User 25
195
User 31
201
User 37
207
User 43
213
User 49
219
User 55
225
User 61
178
User 14
184
User 20
190
User 26
196
User 32
202
User 38
208
User 44
214
User 50
220
User 56
226
User 62
