MP-72/52 G2 Wireless Option
MP-70/50 • MP-72/52 • MP-73/53 • PN 98-0002-29 • REV 1709.13 117
CONTROL TRANSMITTER DIP SWITCH SETTINGS (G2)
Switch
Settings
Description
Factory
Option
1
ON
-
LOW (10 mW) / HIGH (100 mW) Power Level.
-
OFF
LOW (1 mW) / HIGH (10 mW) Power Level.
2
-
ON
Australia frequency band.
OFF
-
USA frequency band.
3
-
-
Not used.
4
-
-
Not used.
SCOREBOARD RECEIVER DIP SWITCH SETTINGS (G2)
Switch
Settings
Description
Factory
Option
1
ON
LOW (10 mW) / HIGH (100 mW) RF Power
Level.
OFF
LOW (1 mW) / HIGH (10 mW) RF Power Level.
2
ON
AUSTRALIA frequency band.
OFF
USA frequency band.
3
ON
The receiver locks onto a signal from only the
SELECT channel. ALL SCBDS channel is
ignored.
OFF
The receiver locks onto a signal from either the
SELECT or ALL SCBDS channel.
4
ON
LOW (RF Power Level).
OFF
HIGH (RF Power Level).
Note: The transmitter and receiver should be set to the same RF power settings
for optimum performance. High power levels are not recommended for
indoor installations.
