Soccer
56 MP-70/50 • MP-72/52 • MP-73/53 • PN 98-0002-29 • REV 1709.13
MINUTES TENS TO CONNECTOR 2 (BOARD TYPE 26)
Note: If you are using a scoreboard other than model FB-8218TK, and you see
this prompt, always press YES.
This setting is exclusive to the FB-8218TK scoreboard
(which uses Board Type 26), and which supports three
sports: soccer, football, and track. It is available only
when you have programmed the MP-70/50 for use with
the FB-8218TK (scoreboard type number 26). See PROGRAMMING THE SYSTEM
SETTINGS on page 142 for more information on scoreboard types.
If you are using the FB-8218TK for football, and you answer YES to
this question, the control will display data in the minutes tens digits of the
scoreboard.
If you are using the FB-8218TK for track and field events, and you
answer NO to this question, the control will display results in the tenths
of seconds digits on the scoreboard.
Note: To complete this change, you will need to connect the appropriate digits in
the scoreboard to connector 2 of your digit driver pack.
FIFA CLOCK
At the prompt shown, press YES if you plan to use
FIFA standards. The FIFA Clock allows the clock count
from zero to 45 minutes for the first half and 45 to 90
minutes for the second half. Overtimes are from zero to
15 minutes and from 15 to 30 minutes.
If you respond YES to the FIFA Clock prompt, the next question you will be
asked is the “T.O. to SCBD? Y/N” question on page 62.
Note: FIFA stands for Fédération Internationale de Football Association
If you choose to play under FIFA standards, the count up clock function is
turned on and the auto horn function is turned off by default. Press the
AUTO HORN key to activate the autohorn function if desired.
COUNTDOWN CLOCK
Press YES if you want the clock to count down
or NO if you want the clock to count up.
- CHANGE SPORT -
MT TO CONN2? Y/N
- CHANGE SPORT -
COUNT DN.CLK?Y/N
- CHANGE SPORT -
FIFA CLOCK? Y/N
