Programming the System Settings
144 MP-70/50 • MP-72/52 • MP-73/53 • PN 98-0002-29 • REV 1709.13
SYSTEM SETTINGS FOR BASEBALL
The following two-page section describes features found on Baseball
scoreboards 31, 33, 34, 35 and 39. The features are shown in order of
appearance. If you do not have these scoreboards, skip to MP-70 AND MP-69
DATA OUTPUTS on page 145.
SETTINGS FOR BASEBALL BOARD TYPE 31 & 35
Press YES at the 4 DIGIT CLOCK prompt
only if you have an MP-7200 scoreboard, then
proceed to MP-70 AND MP-69 DATA OUTPUTS on
page 145.
Press NO if you do not have an MP-7200 scoreboard.
SETTINGS FOR BASEBALL BOARD TYPES 31, 33, 35 & 39
Press YES to the AT-BAT prompt if you want
to display AT-BAT on your scoreboard. Proceed
to MP-70 AND MP-69 DATA OUTPUTS on page
145.
Press NO and the control will default to showing the two-digit clock
instead of AT-BAT. Proceed to MP-70 AND MP-69 DATA OUTPUTS on page
145.
SETTINGS FOR BASEBALL BOARD TYPE 34
If board type 34 has been entered, the prompt shown below appears next in the
sequence of programming questions.
Press YES to NEW H&E DIG prompt if you
want to send 12 segment data to the Hit and
Error digit displays.
Press NO to NEW H&E DIG prompt if you want to send 8 segment
data to Hit and Error digit displays.
SYSTEM SETTINGS
NEW H&E DIG? Y/N
SYSTEM SETTINGS
4 DIGIT CLK? Y/N
SYSTEM SETTINGS
AT-BAT ON SB?Y/N
To Next Page
