The current Gateway IP address
The MAC address of the equipment
Get the MAC address of time.
Select the appropriate network mode. The equipment supports three network modes:
Network parameters must be entered manually and will not change. All
parameters are provided by the ISP.
Network parameters are provided automatically by a DHCP server.
Account and Password must be input manually. These are provided by
your ISP.
If Static IP is chosen, the screen below will appear. Enter values provided by the ISP.
Select the Configured mode of the DNS Server.
Enter the server address of the Primary DNS.
Enter the server address of the Secondary DNS.
attention：
1）After setting the parameters, click【submit】to take effect.
2）If you change the IP operation, the web page will no longer respond, at this time
should be entered in the address bar new IP to connect to the device.
3）f the system USES DHCP to obtain IP at start up, and the network address of the
DHCP Server is the same as the network address of the system LAN, then after the
system obtains the DHCP IP, it will add 1 to the last bit of the network address of LAN
and modify the IP address segment of the DHCP Server of LAN. If the DHCP access is
reconnected to the WAN after the system is started, and the network address assigned
by the DHCP server is the same as that of the LAN, then the WAN will not be able to
obtain IP access to the network
Specify Web Server Type – HTTP or HTTPS
Port for web browser access. Default value is 80. To enhance security,
change this from the default. Setting this port to 0 will disable HTTP
