37
9.16 EGS Setting & Intercom Setting >> Audio
Figure 28 - Audio Setting
Table 13 - Audio Setting
Field Name
Explanation
Audio Settings
Codec Setting
Select enabled or disabled audio codec:
G.711A/U,G.722,G.723,G.729,
G.726-16,G726-24,G726-32,G.726-40,
ILBC,AMR,AMR-WB, opus
DTMF Payload Type
Setting DTMF payload type, the value range must be 96~127.
Default Ring Type
Configure the default ring tone. If no special ringtone is set for the
caller number, the default ringtone will be used.
G.729AB Payload Length
You can select the G.729AB Payload Length ,the options are
10ms20ms30ms40ms50ms60ms.
G.722 Timestamps
You can choose G.722 Timestamps for 160/20ms or 320/20ms.
G.723.1 Bit Rate
You can choose G.723.1 Bit Rate of 5.3 kb/s or 6.3 kb/s.
Speakerphone Volume
Set the hands-free volume to 1-9
MIC Input Volume
Set the microphone volume to 1~9
