Fanvil i32V User Manual

30
Anonymous Call
Standard
Set the standard to be used for anonymous
Dial Without
Registered
Set call out by proxy without registration
Click To Talk
Set Click To Talk
User Agent
Set the user agent, the default is Model with Software Version.
Response Single
Codec
If setting enabled, the device will use single codec in response to an
incoming call request
Ring Type
Set the ring tone type for the line
Conference Type
Set the type of call conference, Local=set up call conference by the
device itself, maximum supports two remote parties, Server=set up
call conference by dialing to a conference room on the server
Server Conference
Number
Set the conference room number when conference type is set to be
Server
Transfer Timeout
Set the timeout of call transfer process
Enable Long
Contact
Allow more parameters in contact field per RFC 3840
Enable the Inactive
Hold
Active capture package SDP is inactive, while the hold is sendrecv.
Active capture package has no response of 400, etc. Hold the hair
inactive
After closing the grab packet, you can see that the DSP is sendonly
and the hold is sendrecv
Use Quote in
Display Name
Whether to add quote in display name
Specific Server Type
Set the line to collaborate with specific server type
Registration
Expiration
Set the SIP expiration interval
Use VPN
Set the line to use VPN restrict route
Use STUN
Set the line to use STUN for NAT traversal
Convert URI
Convert not digit and alphabet characters to %hh hex code
DTMF Type
Set the DTMF sending mode, there are four types:
In-band
RFC2833
SIP_INFO
AUTO
Different service providers may offer different models
DTMF SIP INFO
Mode
When the device's DTMF type is set to SIP_INFO
The DTMF_SIP_INFO type is configured to send */#, and when the

Fanvil i32V Specifications

General

Brand	Fanvil
Model	i32V
Category	Intercom System
Language	English
