FIRST START-UP
CARD G / FIT 16 V 6.15 E / April 2010
A USB memory stick may be attached to the FIT-controller to record operating data. The operator
is allowed to select different kinds of process data which are to be saved.
In case of power failures, data on the USB storage device might get
corrupted. It is highly recommended to save the data regularly to an external
storage medium.
9.2 EXHAUST AIR FILTER
Due to transportation, the exhaust air filter (6.5) is mounted on the inside of the lid. At the first
start up, it must be changed to the outside of the lid.
9.3 LOADING AND UNLOADING
The FIT-controller of the CARD G FIT is programmed to control one loader to automatically load
material into the drying hopper. A venturi type loader (one- or two-components) may be bolted to
the lid of the dryer and connected to the provisions provided on the back of the CARD G FIT. The
electrical power (24V DC) for the solenoid valve of a venturi loader can be plugged to the
connection (3.3). The proximity switch of the venturi loader can be plugged to the connection
(3.2). Compressed air to operate the venturi loader may be taken from the outlet (1.13).
