16. EASY MODE
The EASY MODE supplies
less information in the MAIN SCREEN and allows the operator only to set the most important
parameters.
Only the set point of the drying temperature as well as the suction time for a vacuum loading
device – provided that connected to the CARD G FIT – may be altered in the EASY MODE. The
suction time for loading will only be displayed if device HL (Hopper Loader) is chosen in the menu
for the CONVEYING PARAMETERS which can only be accessed in the EXTENDED MODE operation.
The data screens as well as FAULTS SCREEN and STATUS REPORT are available both in EASY MODE
and E
XTENDED MODE operation. A detailed description of these screens can be found in chapter 17
on page 40.
