EXTENDED MODE
CARD G / FIT 45 V 6.15 E / April 2010
17.2 ENERGY AND DATA SCREENS
17.2.1 ENERGY SCREEN
The ENERGY SCREEN is
accessed from the MAIN SCREEN with the key .
The energy consumption of the process heater and the compressed air consumption of the
CARD G FIT are shown in this screen over a specified period.
The field “TOTAL CONSUMPTION” displays the energy data of the dryer since the first start-up.
The field “DRYING CONSUMPTION” represents the energy data of the current drying process.
The values are reset to 0 when a new drying process will be started.
The field “USER CONTROLLED” shows the energy data over a period of time determined by the
operator using the keys .
