EXTENDED MODE
CARD G / FIT 66 V 6.15 E / April 2010
17.10 SYSTEM PARAMETERS
The SYSTEM PARAMETERS include data which need to be changed only in case of special
applications (for detailed information see SYSTEMS MANUAL CARD G FIT). The parameters can
be accessed after a password has been entered.
The PASSWORD SCREEN is attained from the screen with the DRYING PARAMETERS with the key .
To enter the password, the key must be pressed. A blinking field prompts the operator to
input the password using the numeric keypad. Pressing the key confirms the value.
The message below appears in case of wrong password.
Pressing the key allows the password to be entered once more. The procedure to input the
password can also be abandoned with the key . To return to the MAIN SCREEN the key
needs to be pressed.
