EXTENDED MODE
CARD G / FIT 50 V 6.15 E / April 2010
17.4 DRYING PARAMETERS
The DRYING PARAMETERS are accessed from the MAIN SCREEN with the key . Important data to
define the drying process can be entered in this screen. This and all following input screens are
only available in EXTENDED MODE operation.
All further input screens can be attained from the screen with the DRYING PARAMETERS by using
the keys described in the lower part of the display.
Following parameters can be set in this menu:
SET Temperature
FACTORY SETTING: 60°C [140°F]
The material is dried with this temperature.
If desired, the allowed minimum and the maximum input value being entered can be changed in the
menu with the R
EGULATING PARAMETERS (see SYSTEMS MANUAL CARD G FIT).
CDOWN Timer
FACTORY SETTING: 0h 0m
When the drying hopper is filled the first time, the material must be pre-dried for a certain time. The
CDOWN (Countdown) T
IMER informs the operator as soon as dried material can be removed.
The timer is to be set to the recommended drying time specified by the material supplier. As soon as the
drying process is activated and the temperature in the process circuit is reached within the alarm limits,
the CDOWN timer starts to expire. Once the CDOWN timer has elapsed, the dried material can be
supplied to the production process.
The time is to be set to 0h 0m if the CDOWN T
IMER is not required.
