EXTENDED MODE
CARD G / FIT 49 V 6.15 E / April 2010
The shortcuts in the header of the columns have following meanings and refer to the time shown
in the respective line in the left column:
ST Set point of drying temperature
AT
Temperature in the process circuit
DP
Dew point (if optional dew point meter is installed)
[W]
Power consumption of process heater
[kWh]
Total power consumption since drying has been activated
[Nm³/h]
Compressed air consumption
[Nm³]
Total compressed air consumption since drying has been started
Date and time are written as “08. / 15:31”. The first value shows the day of the current month, the
other two values describe the time of recording.
The key can be used at any time to return from the PROCESS DATA SCREEN back to the MAIN
SCREEN.
