EXTENDED MODE
CARD G / FIT 73 V 6.15 E / April 2010
Unit Temperature
FACTORY SETTING: [C]
The values [C] and [F] might be selected in this parameter.
Depending on this adjustment, the temperature values are indicated as °C (centigrade) or as °F (degree
Fahrenheit) in different screens.
Process Data Cycle
FACTORY SETTING: 30s
The values for the characteristics of the drying temperatures in the MAIN SCREEN and for the data table
in the P
ROCESS DATA SCREEN (see chapter 17.3 on page 48) are recorded at the time interval set in this
parameter.
If more than 250 data sets recorded, each new data set will replace the oldest one.
Retaining the factory setting of 30 seconds traces the drying temperatures in the M
AIN SCREEN and the
data in the P
ROCESS DATA SCREEN over the past 125 minutes.
Dew Point Sensor max.
FACTORY SETTING: +20°C
The highest value of the measurement range of the optional dew point meter is set in this parameter.
The appropriate value can be found on the name plate of the dew point meter.
Dew Point Sensor min.
FACTORY SETTING: -60°C
The lowest value of the measurement range of the optional dew point meter is set in this parameter. The
appropriate value can be found on the name plate of the dew point meter.
Voltage
FACTORY SETTING: 230V
Based on the standard supply voltage of 230 Volts, the electrical power consumption in the ENERGY
SCREEN is calculated.
This value may be altered if the supply voltage to the CARD G FIT unit differs from 230 Volts.
Offset [kWh]
FACTORY SETTING: + 0.0 %
An offset might be set to correct deviations between a measured and the calculated value for the power
consumption displayed in the E
NERGY SCREEN.
The deviation must be entered as a value in percentage.
