20
Dust Extractor
RL 250 / RL 300 / RL 350
Warning! Risk of injury!
Improper assembly and installation can lead to serious physical injury or equipment damage.
For this reason, this work may only be carried out by authorised, trained personnel who are familiar with
how to operate the machine and in strict observance of all safety instructions.
Only assemble and install the machine if the machine and its parts are complete and intact.
6 Setup and installation
• Ensure that there is sufficient space to work around the
machine. Ensure there is ample distance between the
machine and other solid constructions such as a walls
or other machines.
• Keep the work area orderly and clean. Components
and tools that are not put in their correct place or put
away may be the cause of accidents!
• Install the safety equipment according to the
instructions and check that it functions properly.
Warning! Danger of fire!
Unprofessional installation may lead to a fire.
6.1 Safety instructions
Therefore:
• When connecting the machines to the dust extractor, only use steel piping or flame resistant hose and
ensure that these are earthed via metal coil, to prevent the build up of electro static electricity.
• In general when connecting the machines to the extractor, the machines should be earthed to prevent
the build up of electro static electricity.
• All electrical connections must be installed correctly by a qualified person.
• Electricity suppiy only in authorized field of ± 10% of network.
Requirements at the place of assembly:
• A dry, enclosed room.
• Operating/room temperature: +10° to +40°C
• Adequate ventilation e.g. to enable ample air
circulation for the machine cooling system.
• When positioning the machine in a room other
than the workshop, please ensure there is ample
ventilation.e.g. provided through an extractor fan.
Mimimum cross- sectional area 0,25 square meters.
• The working area must have an adequate load-
bearing capacity and stability and the walls must be
stable.
• Even floors without a slope.
• Provide sufficient light at the workstation.
• Ensure there is sufficient clearance for or from
neighbouring workstations.
Setup and installation
Note:
In addition, the vacuum performance must be sufficient to achieve the required negative pressures and an
air speed of 20 m/s at the connector.
Gate valves, Extraction accessories, hose and pipe systems, are available in our „Tools, accessories and
workshop equipment” catalogue!
6.1.1 Setup
