FENDT MAN D 0836 LE - Engine Lubrication Repair: Oil Filter

Fav 900
Engine / Lubrication
Replacing oil filter
G
Repair
Fav 900 chassis number 23/3001and up
14.02.2001
2312 000001
G
a
1/1
Capitel Docu-No.
Index
Date Version
Page
Replacing oil filter
PM-Picturemodule
PM-Picturemodule
PM-Picturemodule
PMTAB_Picture
Replacing oil filter
Caution:
The cartridge is filled with hot oil.
Danger of severe burns.
● Loosen filter lid 2 turns, wait about 5 minutes
until all the remaining oil has drained from the
oil filter housing in the oil pan.
● Remove cover completely .
PMTAB_Picture
● Pullt out filter cartridge with the central guiding
tube.
Collect dripping oil using an appropriate recipient
below cartridge.
● Replace cartridge.
● Replace O-Rings of the central tube and on the
cover.
● Put cover and filter cartridge in place and
tighten at 25 Nm .
PMTAB_Picture
Fill up with engine oil and check for eventual
leaks.
Check oil level.
Note:
Used oil and cartridge are hazardous waste.
