Fav 900
Engine / Generalities
Tightening Torque values
A
General
Fav 900 from chassis number 23/3001and up
13/03/2001
2000 000007
A
a
1/4
Capitel Docu-No.
Index
Date Version
Page
Tightening Torque values
Text-module
Note:
All threaded unions not specified in this table must be tightened according to our works
standard M 3059. Bolts and screws must be lightly oiled before tightening !
Plugs
Crankcase, crank gear
Cylinder head
Lubrication
DIN 908
M 14*1,5; M16*1,5 80 Nm (59,00 lbf-ft)
M 18*1,5; M22*1,5 100 Nm (73,76 lbf-ft)
M 24*1,5; M26*1,5 120 Nm (88,51 lbf-ft)
M 30*1,5 150 Nm (110,63 lbf-ft)
DIN 7604
AM 10*1; M12*1,5 50 Nm (36,88 lbf-ft)
AM 14*1,5 80 Nm (59,00 lbf-ft)
Crankshaft bearing cap on and crankcase
Initial torque 115 Nm (84,82 lbf-ft)
Angular torque 90-100°
Damper on crankshaft M14*1,5 10,9
Initial torque 150 Nm (110,63 lbf-ft)
Angular torque 90-100°
Damper on crankshaft M14*1,5 12,9
Initial torque 150 Nm (110,63 lbf-ft)
Angular torque 90-100°
Angular torque 90-100°
Flywheel on crankshaft
Initial torque 100 Nm (73,76 lbf-ft)
Angular torque 90-100°
Con-rod bearing caps
Initial torque 50-60 Nm (36,88-44,25 lbf-ft)
Angular torque 90-100°
For tightening and retightening of cylinder head bolts see following page
Lock nut for valve adjusting screw 40 Nm (29,50 lbf-ft)
Cheese-head screws with hexagonal socket for bolts of interme-
diate gear
115 Nm (84,82 lbf-ft)
Collar screw for crankshaft 65 Nm (47,94 lbf-ft)
Rocker socket (Torx E12) 65 Nm (47,94lbf-ft)
Oil pressure valve for piston spray nozzle 38-42 Nm (28,03-30,98 lbf-ft)
Oil pump drive gear on shaft 30 Nm (22,13 lbf-ft)
Screw plug for pressure relief valve in crankcase 60Nm (44,25 lbf-ft)
Oil pan drain plug 60Nm (44,25 lbf-ft)
Screw plug for oil filter head (M 10*1) 20 Nm (14,75 lbf-ft)
Threaded coupling for oil filter 40 Nm (29,50 lbf-ft)
Screw plug in oil filter (M 18*1,5) 30 Nm (22,13 lbf-ft)
Screw plug in oil filter (M 24*1,5) 30 Nm (22,13 lbf-ft)
Screw plug in oil filter (M 30*1,5) 40 Nm (29,50 lbf-ft)
OIl change filter 25 Nm (18,44 lbf-ft)
