Fav 900
Engine / Generalities
Tightening Torque values
A
General
Fav 900 from chassis number 23/3001and up
13/03/2001
2000 000007
A
a
2/4
Capitel Docu-No.
Index
Date Version
Page
Tightening Torque values
Cooling system
Exhaust / Intake manifolds
Fuel system
Starter / Alternator /Compressor
Sensors
Screw plug in coolant pipe (M14*1,5) 20 Nm (14,75 lbf-ft)
Hose clips :
Clamping range 12 to 31 mm, 9 mm wide 3,6 Nm (2,66 lbf-ft)
over 32 mm, 13 mm wide 5 Nm (3,69 lbf-ft)
Exhaust manifold on cylinder head
Initial torque 50-55 Nm (36,88-40,75 lbf-ft)
Angular torque 90-100°
Banjo bolt of solenoid valve 10-15 Nm (7,38-11,06 lbf-ft)
Knuckle pin clap of turbocharger 12 Nm (8,85 lbf-ft)
Nozzle holder in cylinder head 70 Nm (51,63 lbf-ft)
Nozzle adjusting nut 45 Nm (33,19 lbf-ft)
Banjo bolt for leak oil 10-12 Nm (7,38-8,86 lbf-ft)
Pressure line at nozzle
Initial torque 10 Nm (7,38 lbf-ft)
Angular torque 60°
Banjo bolt on oil filter 20-30 Nm (14,75-22,13 lbf-ft)
Fuel filter 10-15 Nm (7,38-11,06 lbf-ft)
Purge plug on fuel filter 8-10 Nm (5,90-7,38 lbf-ft)
Alternator pulley 75-85 Nm (55,32-62,69 lbf-ft)
Compressor drive gear 200-250 Nm (147,51-184,39 lbf-ft)
Oil pressure sensor 80 Nm (59,00 lbf-ft)
Temperature sensor switch 15 Nm (11,06 lbf-ft)
Coolant Temperature sensor (EDC) 35 Nm (25,82 lbf-ft)
